Texas International Oilfield Tools Mfg. 250 Ton Elevator/Spider

Texas International Oilfield Tools Mfg. Skid Mtd. Power Unit Deutz

Texas International Mfg. Skid Mounted Power Unit driven by 6 cylinder Deutz motor air operated or electric start, leakage confirmation, Spark arrester, hydraulic cooler, positive air shutdown (mechanical), belt break shutdown, complete with 50 ft. hose.

Texas International Oilfield Tools Mfg. Skid Mtd. Power Unit Electric

Texas International Mfg. Skid Mounted Power Unit driven by 100 HP 60Hz electric motor (50 Hz available), two stage gear type hydraulic pump, capable of producing 79 GPM at 1000 PSI, 37 GPM at 2500 PSI. Complete with hydraulic oil cooler along hydraulic reservoir, relief valve, remote start/stop station and 50 ft. hose system or other configurations.

Texas International Oilfield Tools Mfg. Kelly Spinner

Kelly Spinners can be used for rotating drill pipe slowly, for limited rathole and mousehole drilling and making fast kelly connections. These units are completely reversible; the driller can spin out, as well as spin in, when making connections, therefore, spinning chains are not required.

Elevator Weldless Links-Varco & Texas International Oilfield Tools Mfg.

Elevator Weldless Links - 4 -1/4" thru 1-3/4"
Elevator Weldless links are forged from a single piece of high-grade alloy steel to provide maximum tensile strength. More weight and “plus-diameter” in critical areas make these links extra strong. Short upper eye design means better balance and easier elevator handling, while reducing wear of the eye section against the swivel bail or body.

Texas International Oilfield Tools Mfg. Rotary Slips

SDS, SDML, SDXL and SDHL Rotary Slips are for use in API standard insert bowls. Featuring better contact and distribution of load on drill pipe thru a superior wraparound configuration and unique insert design, these slips prevent bottlenecking and gouging damage. The buttress design of the body segments provides great strength while minimizing weight for ease of handling.

Texas International Oilfield Tools Mfg. Flush Mount Spider

Texas International Oilfield Tools Mfg. Wireline Unit

Farr Power Tongs-KT20000-20" 50K

Texas International Oilfield Tools LTD. is the worlds largest stocking distributor for Farr Canada.

We stock power tongs. In-stock & ready to ship!

Farr Power Tongs-KT13625-13-5/8"

The Farr Hydraulic Power Tong has been designed such that assembly is simple and can be accomplished without the use of special tools. The following sequence is presented as a guide only for the technician performing assembly as it would take place in our plant. Much emphasis has been placed on disassembly and reassembly in the maintenance and overhaul section of this manual. It is, therefore, recommended that this assembly section be used only to aid in familiarization of parts and their locations, and the overhaul and maintenance section be used as a specific guide to assembly.

Farr Power Tongs-LW9625-9-5/8" - 12K

We carry hard-to-find parts, will customize for you. Call Texas Internationa today for more information (888) 318-0703.

Over the years Texas International has built a reputation for providing their customers with the proper equipment to accomplish their objectives and the desire of to keep up with the industry's changing needs.

Farr Power Tongs-KT7585 8-5/8" 25K

Torque Range:
High Gear: 5,000 ft-lbs. / 6780 Nm
Low Gear: 25,000 ft-lbs. / 33900 Nm
Maximum RPM @ 60 GPM / 227 LPM
High: 48 RPM
Low: 9 RPM
Hydraulic Requirements (max.): 60 GPM @ 1,000 PSI / 227 LPM @ 6.9 Mpa
10 GPM @ 2,000 PSI / 37.8 LPM @ 13.8 Mpa
Length: 56 inches / 142.2 cm
Overall Width: 30 inches / 76.20 cm
Space Required on Pipe: 8 inches / 20.32 cm
Maximum Elevator Diameter: Unlimited (tong comes off pipe)
Torque Arm Length: 36 inches / 91.44 cm
-centerline of pipe to centerline of anchor-

Farr Power Tongs-KT5500

KT5500 18K Hydraulic Tongs

Hydraulic Requirements (max.): 50 US GPM@1000 psi (189 LPM @ 6.9 MPa)
10 US GPM@2000 psi 38 LPM @ 13.8 MPa)
Length: 52 inches / 132.1cm
Height: 33 1/4" / 84.5 cm
Width: 25 1/2" / 68.4 cm
Space Required on Pipe:: 6 3/4"/1731 cm
Maximum Elevator: N/A
Torque Arm Length: 36"/91.4 cm
-Centerline of pipe to Centerline of anchor

Farr Power Tongs-KT5500 with Back-up

KT5500 5 1/2"-18K Farr Power Tong with Back-up Hydraulic Requirements (max.): 50 GPM @ 1000 psi (189 LPM @ 6.0 MPa) 10 GPM @ 2000 psi (38 LPM @ 13.8 MPa) Length (Doors Closed): 52"/132.1cm Height: 60"/152.4cm Width: 37"/94cm (Model 80-0421-3 Tension LC) 35"/89cm (Models 80-0422 & 80-0406 Comp LC) Space Required on Pipe: 6-3/4"/17.1cm Maxiumum Elevator Diameter: N/A Torque Arm Length: 30"/76.2cm (Tension Load Cell Configuration) 32"/81.3cm (Compression Load Cell Configuration) - Centerline of pipe to Centerline of anchor -

Farr Power Tongs-SL4500 -Perfect for Workover Rigs

Farr Canada’s newest tubular connection tool offers a significantly reduced rig footprint, while continuing to deliver power and uncompromising reliability. The simple design drastically cuts maintenance andSL4500 SLIM FARR POWER TORQUE with or without Hydraulic Backup overhaultimes, and the hydraulic shifter mechanism conveniently allows operators to “shift on the fly”, eliminating the need to stop the tong to shift gears.

This tong and backup* combination is available in high torque and low torque versions. The SL4500 is available with a variety of options including (but not limited to): a “mono-rail” rigid sling, dual-rail rigid sling, safety door kit and Farr’s patented WinCatt data acquisition and torque control system for the makeup of tubular connections.

WinCatt™ Torque Turn System

WinCatt™ is a software tool which interacts with external control hardware to provide real time monitoring and control of tubular connection power tong make-up. The graphical user interface and logical software structure combined with powerful control, data acquisition and presentation capabilities enable the user to easily specify make-up parameters, control the make-up process and evaluate quality.

WinCatt™ was developed with an emphasis on the user's needs for reliability, accuracy, and ease of use.

Varco 250 Ton Elevator/Spider

BJ 250 Ton Elevator Spider 2 3/8in - 7 5/8in

Varco 750 Ton Elevator/Spider

750 TON ELEVATOR/SPIDER ASSEMBLY 14"

BJ 350 Ton Elevator/Spider

BJ 350 Ton Elevator/Spider 4-1/2" - 13-3/8"

Varco Flush Mount Spider

The FMS 275/375 is mounted flush with the rig floor, allowing the casing connection height to be lowered 1 meter (3 feet), thus eliminating the need for scaffolding. The rig crew also has more room to work by removing the spider body from the top of the rig floor. The units are designed to fit into standard 271/2" (FMS 275), 371/2" and 491/2" (FMS 375) rotary tables.

Varco API Bowl

8 5/8" API Bowl
10 3/4" 100 Ton Bowl

Single Joint Elevators

Single Joint Elevators, sizes 2-3/8"-30" 5 Ton

SLX Side Door Elevator 100 - 500 Ton

The X-series elevators handle all sizes of collar-type tubing, drill pipe and casing. The SLX has a shielded safety latch mounted on the elevator door. The shield protects the latch from accidental opening. Both latches operate from a single handle, and then automatically relatch when the elevator door is closed. The Type SX side-door elevator, designed for handling large, collar-type casing, is a sturdier, safetylatch-equipped version of X-series elevators.

Center Latch Elevator TA100 & TA150

Center-latch elevators are for handling collar-type drill pipe, casing and tubing. All "A" type elevators are constructed in two halves of practically the same weight, providing proper balance and easier opening and closing. In open position, the elevator hangs ready for closing at any point below the upset of the pipe. All "A" type elevators feature latch and safety latch lock combinations. Safety features include guarded operating handles to help prevent accidents to operators and an extra handle at the rear of the elevator for safer operation.

Texas International Oilfield Tools Mfg. MYT 40 Ton Elevator

SLIP TYPE ELEVATORS Y SERIES TI Mfg."Y" series elevators are conventional slip type elevators for handling tubing and small casing. The elevators function as companion tools for the TI Mfg. tubing spiders. All type "Y" series elevators operate with the latch lock combination for safety.

Texas International Oilfield Tools, LTD We have all the necessary tools to outfit your needs.

BJ Y-Series Casing/Tubing Elevators

Varco BJ "Y" series elevators are conventional slip type elevators for handling tubing and small casing. There are 7 types ranging from 20 to 200 ton capacity and covering pipe sizes from 1.050" to 7 5/8" OD. They feature a four slip design which give an optimum contact on the pipe to prevent bottlenecking and gauge damage. These elevators function as companion tools for the Varco BJ tubing spiders. The Varco BJ "YC" type elevator is capable of handling dual tubing strings. All type "Y" series elevators operate with the latch lock combination for safety. The "MYC" and "YC" provide a 7" and the "HYC" a 10 1/2" of insert contact to grip your casing or tubing. Click MORE for information.

Texas International Oilfield Tools Mfg. Hinged Spider 200 / 500 Ton

Con-Tech Thread Protectors

ConTech manufactures Casing Thread Protectors (for 8 round, buttress and premium threads) in sizes from 4-1/2" to 16". These quick latch protectors offer advantages in durability, weight, and reduced cost over other products and because of their non-ferrous metal latch assembly, they are acceptable for hazardous areas!

Texas International Oilfield Tools Mfg. Pneumatic Tubing Spider

All pneumatically controlled units operate using rig air. To maximize crew safety, the system may be manually operated if rig air pressure is lost. Safety is further ensured by a positive locking mechanism which locks the slips in the set position.

Kelly Drive Bushings-HDP, HDS

HDS ROLLER KELLY BUSHING - For heavy duty square drive applications. Components are interchangeable with HDP. Unit comes with wrench, wiper and wear gauge. Weight 1420 lbs.

HDP ROLLER KELLY BUSHING - Widely recognized as the standard of the industry. For master bushings with 25 ¾" pin circle 27 HDP of 23" pin circle, 20 HDP. Unit comes with wrench, wiper and wear gauge. Weight 1500 lbs.

Drill Bowls #1, #2, #3

We stock hard-to-find parts, will customize for you. Call Texas International Oilfield Tools, LTD. for more information (888) 318-0703.

Varco Spinning Pipe Wrench-SSW40

Proving the old saying that “Good things come in small packages”, the Varco SSW-40 is not only small in size but also the most powerful pneumatic spinning wrench on the market.

In a typical spinning operation the rig hand swings the SSW-40 onto the pipe just above the joint upset. The clamp control is pulled and the throttle handle actuated to spin in or out with absolute precision. For added safety spin direction lockout feature is included to prevent spinning pipe in wrong direction.

Varco Spinning Pipe Wrench-SSW30

The hydraulically powered SSW 30 can spin drill pipe and drill collars from 2 7/8” to 9 1/2” O.D. with no adjustments necessary. Its abundant power will bump up shoulders tight enough so each joint is quickly torqued.

This lightweight tool is narrower and has lower profile than previous spinning wrench designs. It achieves its compact shape by using one large cylinder for clamping instead of two.

Varco Spinning Pipe Wrench-SSW10

The Varco Safety Spinning Wrench, SSW 10, is a pneumatically powered tool for spinning drill pipe from 3 1/2” to 5 1/2” O.D. Using the proven principle of frictional drive contact, the spinning wrench can spin drill pipe in or out quickly and efficiently without damage to expensive drill pipe and without the hazards of the dangerous spinning chain..

Varco & AOT Drill Pipe Elevators

G series elevators are similar in design and construction to the A series, except they are bored to fit the contour of 18º type drill pipe. They are constructed in two halves of practically the same weight for better balance, making them easier to handle; easier to latch on and take off the pipe. In open position, a G-series elevator hangs ready for closing at any point below the upset of the pipe. Safety features include guarded operating handles to help prevent accidents to operators and an extra handle at the rear of the elevator for easier, safer operation.

Master Bushings

MSPC Master Bushing 20 1/2" through 27 1/2" The 20 1/2" thur 27 1/2" MSPC is a solid Body Pin Drive Master Bushing designed for all drilling operations. The pin drive allows the kelly bushing to ride on top of the rotary table and permits extended bowls to be sued for better slip back up. With the extended API insert bowl No. 3, the MSPC will handle tubulars from 2 3/8" to 13 3/8".

Safety Clamps

Type "C" & Type "T"

We stock hard-to-find parts, will customize for you. Call Texas International Oilfield Tools, LTD. for more information (888) 318-0703.

UC-3 Casing Slip-7"-36"

Most casing strings' weight and the relatively thin pipe wall make it important that the supporting slips UC Casing Slip, All types of Pipe Handling Tools availableprovide full circumferential grip. The BAASH-ROSS Type UC-3 slips achieve this with many narrow segments. They are hinged together to wrap around the casing and exert a more uniform pressure. With each segment carrying the same load, they automatically center the casing string within the bushing or spider. The UC-3 has a 3" taper. With changes in the number of segments and liners, it will handle strings from 16" OD to 42" OD. Liners are held in place by a liner Retainer Key and Cotter Pin.

CMS-XL-6 5/8"-36"

EXTRA LONG MULTI-SEGMENT CASING SLIPS Today's deeper drilling calls for long and heavy casing strings. Varco has slips to handle any casing job. Varco CMS-XL slips are manufactured from drop forgings, reinforced to take severe service. The self-centering full wraparound grip prevents damage to casing. With certain simple adjustments, the CMS-XL can accommodate casing from 6 5/8" to 30" OD. All Varco BJ slips have an API taper of 4"/ft on the diameter.

Drill Collar Slip DCS-S, DCS-R, DCS-L

Each slip segment is a rugged drop forging with an extra long back to provide maximum support to the circular button gripping elements. Full wraparound design and circular buttons assure positive holding and slip setting. Drill collar slips are flat on top to accommodate the MP clamp. All Varco slips have an API taper of 4"/ft on the diameter.

Manual Tongs-Varco, Access Oil Tools (AOT)

BJ/Varco Manual Tongs - BJ-HT35, BJ-HT65, BJ-HT100
AOT Manual Tongs - Type B, Type C-HT35, HT65 and HT100.

DU Rotary Regular Slip (available with Flex handles)

The “DU” Rotary slips are designed for long trouble free service. They are made of alloy steel and heat-treated for strength and resistance to wear. Both slips are for use in API tapered bowls. The “DU” regular has a 12” long gripping surface and is designed for wells 8000’ or less.

DU Rotary Long Slip w/Flex Handles

The “DU” Rotary slips are designed for long trouble free service. They are made of alloy steel and heat-treated for strength and resistance to wear. Both slips are for use in API tapered bowls. The AOT “DU” Long has a 16” long gripping surface and is designed for deep wells and heavier drill strings.

Texas International Mfg. Hydraulic Cathead EZY Torque

Texas International Mfg. Hydraulic Cathead EZY Torque, Model D type I Precision Torque range 40,000-150,000 ft/lb. Complete with remote control, hydraulic power unit 50/60 HZ, 460 V.

BJ Type Bell Guide

BJ Type Upper Guard

We stock hard-to-find parts, will customize for you. Call Texas International Oilfield Tools, LTD. for more information (888) 318-0703.

Top & Bottom Guides for BJ & Varco Type

Precision Die Technology Dies & Inserts

Precision Die Technologies inserts are machined, not cast, to provide the accuracy required for today's critical applications. Our dies are heat treated to provide maximum insert life. A variety of tooth pattern are available to securely grip the hardest strings of casing, tubing and drill pipe.
